Blackmagic URSA Cine Studio Viewfinder

Display Size

7 inch.

Display Resolution

1920px x 1200px.

Display Type

LCD capacitive touchscreen.

Display Brightness

2000 nits.

Frame Rates

Up to 60fps.

Handles

Built in grab handles for positioning the monitor independently from the camera.

Position Adjustment Options

Articulated yoke with variable tension pivots and grab handles for forward, backward, up, down, pan and tilt adjustments.

Sunshade

Detachable and foldable sunshade

Mounting Options

Quick release V-lock mounting bracket for attaching viewfinder to URSA Cine 12K body.

Tally

Large talent facing LED tally light with customizable perspex camera numbers.

Metadata Support

Viewfinder supports all camera metadata and full Blackmagic OS camera control.

Controls

Touch screen with heads up display and full camera control,

Push button dial for settings and navigating menus,

Customizable short cut function buttons,

Dedicated brightness, contrast and peaking knobs.

On Screen Controls

Tap screen to control Monitor Overlays, Frame Rate, Shutter, Iris, Timecode, ISO, White Balance, Tint, Power, Record Start/Stop, Media, Audio, Focus Zoom, Digital Slate and camera menus.

Button Controls

Includes F1, F2, F3 assignable function buttons to recall preset parameters or toggle functions plus BACK button.

Function Button Toggle

Clean Feed

Status Text

Display LUT

Frame Guides

Focus Assist

False Color

Zebra

Grid

Safe Area Guide

Off Speed Rec

Focus Zoom

Focus

Record

Auto White Balance

Color Bars

Playback

False Color + Zebra

OIS

Stream

Still
