Blackmagic Cloud Store Ultra 24TB is an extremely high-performance network storage solution in a compact 1RU design with server-style front-to-rear cooling. Cloud Store Ultra features 24TB capacity 12-card RAID 0 flash memory core, 2 x 100G Ethernet ports, RAID 5 support for data protection, two redundant power supplies, USB-C and Blackmagic Cloud Sync for distributing files globally. It’s fast, even with lots of simultaneous users all accessing files at the same time.
2 x 100G QSFP28 connections.
Each 100G port can be assigned an independent IP address and subnet mask for up to 200G bandwidth and load balancing when used with a managed switch.
Please click here to view supported QSFP28 modules.1 x RJ45 Ethernet. Supports 10/100/1000 BASE-T. For Cloud Store Setup utility and software updates.
2
1
1.5G, 3G.
1 x USB-C for Cloud Store Setup utility and software updates.
2 x IEC C14 power inputs.
NFS
SMB
200 max.
M.2 NVMe SSD
24TB
Built in 2.2 inch LCD for settings plus storage name, capacity and use.
Device Name, storage capacity and use, Cloud Sync status, User Activity, Hardware Status, storage map, network data rate graph.
1080p50, 1080p59.94, 1080p60
1080p50, 1080p59.94, 1080p60
3 buttons, 2.2 inch color display and spin knob for menu settings.
USB-C or Ethernet for configuration and software updates.
Blackmagic Cloud Setup Utility
Internal software upgrade via Blackmagic Cloud Setup using USB-C or 1G Management port.
2 x 100 ‑ 240V AC 50/60Hz internal power supplies.
2 x IEC C14 sockets.
TBC
1 rack unit.
5° to 40° C (41° to 104° F)
-20° to 45° C (-4° to 113° F)
0% to 90% non‑condensing
Blackmagic Cloud Store Ultra 24TB
Welcome wallet with QR code for software download
1 Year Limited Manufacturer’s Warranty.
